500w 510w 520w Monocrystalline Sunpower Solar Panel Module

Ask Lasest Price
Brand Name :	Bright
Model Number :	BR-SP-500
Certification :	CE/TUV/ISO/IEC/ EMC
Price :	USD0.23-0.30/watt
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	50000pcs/month
Delivery Time :	15-25 days after receiving 50% deposit

Add to Cart

Product Details
Company Profile

500w 510w 520w Monocrystalline Sunpower Solar Panel Module

Bright 480w 490w 500w 510w 520w Monocrystalline sunpower solar panel module

Product description

Inverters are critical components of solar panel systems because they convert direct current (DC) electricity produced by solar panels into usable AC electricity for your home's use. With AC modules, the electricity is converted to AC right at each panel rather than traveling from the panels to a central inverter.

e.g. a 1 kW solar system can produce 1 kW of power per hour on sunny days. kWh stands for kilowatt-hour. 1 unit of electricity implies 1 kW generated/ utilized in an hour. You need to install at least 3-4 solar panels based on watt peak in an array for the 1 kW solar system.

Product parameter

Photovoltaic Modules
Size and Number of cells	156mm156mm 96/812pcs
Maximum Power Pmax	480W	490W	500W	505W	510W	515W	520W
Maximum Power Voltage (Vmp)	48.70V	48.90V	49.10V	49.10V	49.30V	49.30V	49.50V
Maximum Power Current (Imp)	9.86A	10.02A	10.18A	10.29V	10.34A	10.45A	10.51A
Open Circuit Voltage (Voc)	58.44V	58.68V	58.92V	58.92V	58.16V	59.16V	59.40V
Short Circuit Current (Isc)	10.35A	10.52A	10.69A	10.80A	10.86A	10.97A	11.03A
Cell Efficiency	20.96%	21.40%	21.83%	22.05%	22.27%	22.49%	22.71%
Module Efficiency	18.92%	19.32%	19.71%	19.91%	20.10%	20.30%	20.50%
Tolerance	0+3%
Max System Open Circuit Voltage	1500V
Max Series Fuse Rating	15A
Junction Box (protection degree)	≥IP67
Dimension	1956131040mm
Weight	27.5kgs
Operate Tempereture Scope	-40/+85℃
Relative Humidity	0-100%
Frame Thinkness	40/45/50mm
Frame Colour	Black/Siliver

Main features

Standard Test Conditions[STC]:irradiance 1000W/m2; AM 1.5; module temperature 25℃, Measuring uncertainty of power is within ±3%.

Tolerance of Pmpp:0~+3%.Certiffied in accordance with IEC61215,IEC61730-1/2.

Delivery & Payment Terms

Payment Terms	T/T	EXW	30% in advance for deposit payment, the balance payments will be paid before shipment.
		FOB
		CFR/C&F	30% in advance for deposit payment, the balance will be paid against copy of B/L
		CIF
	L/C	For the amount of one shipment above 50,000 usd, L/C at sight is acceptable.
	West Union	For the amount less than 5000 usd
	Paypal
Delivery Time	7~25 days after receiving the payment or the deposit payment
