Ready To Ship In Stock Fast Dispatch Super Bright Hot Selling IP65
60W Factory Sale Outdoor Waterproof All In One Smar
Product design concept:
1. The integrated series, derived from BNE, every detail design and
material that is playing its
greatest role to support a great extreme sport!
2. BNE series solar lights get rid of redundant wiring, make every
detail to play its greatest value
from the reasonable configuration of the core components to the
unique appearance design,
realizes energy-saving, safe and convenient!
3. BNE dedicated to make excellent solar lights. Selling and using
will be rest assured.
Product features:
1. Large Monocrystal Silicon Solar Panel
2. High Luminous Efficacy LED Chip from Germany
3. 100% Charging and Discharging Test
4. Over-loaded or Over-discharged IP Protection
5. Large Capacity Li-ion Battery
6. Industrial Grade High Strength ABS Raw Material Shell
7. Intelligent Control PIR Human Body Sensing Chip
Product specification:
| Name | Features |
| Lighting Mode | Sensing Mode / Sensing+Dim Mode / Continuous Lighting Mode |
| Sensing Method | Human Infrared Sensing, Beam Angle:120°, Distance: 0~8m |
| Solar Panel | Monocrystal Silicon Laminate Panel, 5.5V/1.8W, Conversion Efficiency≥20% |
| Battery | Li-ion Battery: 3.7V 2000mAh |
| LED Light Source | OSRAM 2835, 0.5W/18PCS |
| CCT/CRI | 3000K/4000K/6000K, CRI>80 |
| Power | 3.5W |
| Luminous Flux | 150LM/W |
| Charge Time | 6~8H |
| Lighting Time | >12H |
| Protective Function | Overcharge/ Over discharge /Short Circuit Protective |
| IP Rating | IP65 |
| Operating Temperature | -20~60℃ |
| Product Size | L220*W109*H45mm |
| Net Weight | 220G |
Product advantages:
1. 0 energy consumption: zero electricity bill, zero wiring, zero
maintenance, zero
energy consumption, zero danger, zero pollution, zero carbon, zero
management.
2. Patent Pending Design: the shape and design has been carefully
studied to
optimize all the construction. The outlook should be nice to be
seen. This is why
we have the best solution with the best assurance on the market.
3. Lithium Battery: Using lithium battery to prolong product life
and protect environment.
We apply the newest technology on our street lamps. The lithium
batteries are the future.
4. Anti-Corrosion: Our products are designed for rustproof,
waterproof and dustproof.
All these features combine to create an unnique product.
Product installation instructions:
1. The ex-factory of the standard components of the LED street
lights include a 3*1mm2 cable.
The power supply wire should suffer the voltage ≥300/500V,the
copper cross-section ≥ 0.75
mm2 of 3 copper wires inside. The installation and wiring
connection should be carried out after
turning the power off. Before wiring connection, the operator must
check the polarity of power
supply to prevent the damage of controller fuse and lamp.
2. Insert the street light holder into the pole arm. The diameter
of pole arm is 50 mm. The length
of connective part is 60-65mm.Adjust lamp to desired level, wrench
the M8 secure screws until tightened.
3. Switch on the power and make sure the light is on. Then the
installation is done.
FAQ:
Q1. Can I have a sample order for led solar light?
A: Yes, we welcome sample order to test and check quality. Low MOQ,
1pc for sample checking
is available. Mixed samples are acceptable. Other questions
Q2. What is your terms of payment?
Usually, we accept T/Irrevocable L/C at sight. For regular orders,
Terms of payment 30% deposit,
full payment before deliver the goods.
Q3. You are manufacturer or trading company?
We are factory. Welcome to visit our factory at any time.
