| Mode | BR-IN-1000 | BR-IN-1500 | BR-IN-2000 | BR-IN-3000 | BR-IN-4000 | BR-IN-5000 | BR-IN-6000 | BR-IN-7000 |
| rated power | 1000W | 1500W | 2000W | 3000W | 4000W | 5000W | 6000W | 7000W |
| peak power | 3000W | 4500W | 6000W | 9000W | 12000W | 15000W | 18000W | 21000W |
| Input | Voltage | wide input voltage range(130V-280V AV) or narrow input voltage
range(160V-260V) is optional |
| Frequency | 45-65Hz |
| Ouput | Voltage | AC220V±3%(battery mode) |
| Frequency | 50/60Hz±1%(battery mode) |
| Output waveform | Sine wave |
| Efficiency of the whole machine | ＞85% |
| Battery type | Lead-acid,lithium-iron,gel,ternary and customized |
| Nominal voltage of external battery | 12/24/48VDC | 12/24/48VDC | 24/48VDC |
| Max charging current of mains supply | 80A(12VDC),40A(24VDC), 20A(48VDC) |
| Protection | Overloaded,short-circuit, over-temperature, over/low voltage of battery,
over/low voltage of mains supply protection |
| Conversion mode | Interactive 5MS(typical) |
| Overload capacity | Maintain 60 seconds when 110%-120%, maintain 10 seconds when 150% |
| Communication interface | RS-232(optional) |
| Operating environment | Temperature | 0-40℃ |
| Humidity | 10%-90% |
| L*W*H(mm) | 370*210*170mm | 485*230*210mm | 540*285*210mm |
| N.W(KG) | ? | ? | 16 | 21 | 27 | ? | ? | ? |
Product Description
With reliable intelligent design ,GS series 12000w solar inverter
can be available to complicated appliances.Not only used for common
appliances such as TV,computer,lights,fans ect,but also suitable
for inductive loadings such as
refrigerators,airconditioners,motors,pumps,compressors and laser
printers.
Features
1. With MPPT solar charger controller built inside.
2. Wide PV input range, can work without battery.
3. Remote&Removable LCD control module with various communication such as WIFI/RS485/RS232 optional for SUNON PLUS.
4. Smart and intelligent pure sine wave, high frequency
technology,wall amounted design,light weighted and easy to operate.
5. Select-able charging current based on applications
6. Configurable AC/Solar input priority via LCD setting
7. Compatible with (LI Ion, LiFePo4 and etc.), batteries with BMS system and battery equalization
8. Auto restart while AC is recovering, auto charge and switch,
unattended operation 9. Smart battery charger and management for optimized battery
performance
10. High Efficient DC-To-AC Conversion.Minimizing Energy Loss and self
power consumption
11. around protection functions: Overload/short circuit protection/high
voltage/low battery voltage/high temperature,etc.
Advantages:
Compared with the high-frequency inverter and the power frequency
inverter, the power frequency inverter has the complementary
function of the city power, the UPS uninterrupted power supply
function; the electrical appliances are constantly powered. Because
the built-in high-power transformer (low-frequency transformer)
isolates the power amplifier tube, the load capacity is strong,
impact resistance; it is not easy to damage, and the service life
is long. There is the complementary power supply of the city power
inverter; the city power charges the battery, and the inverter can
be suitable for various batteries on the market. Customers can
define and adjust various parameters by themselves.
FAQ
1. Q: Can I have sample before formal order?
A: Sure, it will be warmly welcomed.
2. Q: What's the warranty:
A: 24 months for free.
3. Q: What's the payment methods?
A: Usually we accept T/T (Telegraphic Transfer)
4. Q: OEM is available?
A: Yes, OEM is welcomed.
